Sample Drawings Overview

Our CADD products meet U.S. Department of Defense Military Standards (MIL-STD) & American Society of Mechanical Engineers (ASME) Standards.  The samples below illustrate our expertise with these industry standards.

Samples were produced by a CADD Drafter with a fair amount of imagination, turning either existing objects in inventory or purely conceptual objects into these “samples” in less than 40 man-hours without the input of the Project Engineer.

The following drawings are in compliance with MIL STD/ASME Y14.100 and subtier standards and are for demonstration of drafting standards only.

Click on an image to see it larger.



Helmet – Overview Design

clip_image010_0000

Coffee Press Sample

COFFEE-PRESS-FRAME-AND-VESSEL-web



Stove Adapter Ring

STOVE-DRAWINGS-ADAPTER-RING-&-BURNER-web


Cyber Glasses – Right Temple Design

clip_image008_0000

Cyber Glasses – Left Temple Design

clip_image006_0000

Cyber Glasses – Frame Design

clip_image004_0000


M375 Series – Optical Guidance Package Mock-up

clip_image002_0000


For a list of our commonly used equipment and software, see this page.
